The ductless fume - type medicine cabinet series is specifically designed for the storage of toxic and harmful chemicals. It is applicable to various fields and different types of chemicals. It can store most of the chemicals used in laboratories, purify the toxic gases inside the cabinet, and purify the laboratory air 24 hours a day, being highly efficient and environmentally friendly.
Metal Components: The main material is galvanized steel sheet with a thickness of ≥1.2mm. It is coated with epoxy resin through electrostatic spraying and has a durable chemical - resistant and lead - free coating, maintaining a high degree of smoothness and minimizing the impact of corrosion and moisture.
Door Panels: The main material is acrylic sheet with a thickness of ≥6mm. It has excellent weather resistance, outstanding chemical - resistant properties, is not prone to aging, is colorless and transparent, allowing light to pass through evenly, providing a comfortable visual experience, and presenting an elegant appearance.
Shelf Boards: It has an integrally - formed PP tray, which is resistant to acids and alkalis and can be adjusted in height. A uniformly - perforated galvanized shelf board can be optionally configured.
Acid - and - Alkali - Resistant Leak - proof Drawer: The inner liner is made of polypropylene (PP), which is corrosion - resistant and can prevent liquid leakage in case of broken reagent bottles.
Seven - inch LCD Touch - screen Display: With a high - definition display resolution of 1024*600, it offers a perfect visual system.
Real - time Temperature and Humidity Monitoring System: It displays real - time temperature and humidity and allows setting of alarm parameters to ensure the safe use of the product.
Fan Monitoring: Alarms when the fan system malfunctions. The fan speed can be adjusted online to meet the storage requirements for different amounts of chemicals.
Filter Saturation Alarm System: The saturation alarm value of the filter is set. An alarm will be triggered when it exceeds the range, corresponding to the VOC concentration level. When both the alarm and the concentration level are at a high position, the filter needs to be replaced.
Imported PSC Fan from the US: With a voltage of 24 volts, it has stable performance, is ultra - quiet, and generates no sparks or static electricity.
High - efficiency Filtration System: Filters are arranged and distributed according to particle size, following ASTM standards. It is effective against acidic gases and organic gases with strong adsorption capacity. For particle filtration, a high - efficiency HEPA filter is used, achieving a filtration efficiency of 99.995% for particles larger than 0.3um.
LED Light Strip: Its power is equivalent to that of a 25W fluorescent lamp. It generates no heat, is safe, does not affect the temperature of the experimental environment, and is energy - saving, environmentally friendly, and has a long lifespan.
No need for pipeline installation projects. It is easy to install, does not discharge waste gas externally, and is a new type of environmentally friendly product.
A filter module system can be optionally configured on the top according to the type of chemicals to meet the storage of various different types of chemicals.
Advanced modular filtration technology can completely adsorb and filter harmful gases, particulate dust, and other substances generated during experiments.
It does not consume air - conditioning energy, achieving high - efficiency energy savings.
It is easy to move, can be stored nearby, and is convenient for access, improving work efficiency.
Fan
The fan located at the top of the cabinet sucks the air in the laboratory into the cabinet, creating a negative pressure.
Gas Filtration
The harmful gases volatilized from the reagents stored in the cabinet enter the filtration module through the fan. The molecules of toxic and harmful gases are intercepted and filtered by the filter, and the clean gas returns to the room.
High - quality Air Purification Function
The filtered clean air returns to the room and will not harm the health of personnel.
Purifying Laboratory Air
It purifies the air in the laboratory 24 hours a day, improving the air quality in the laboratory. (It is recommended to keep the medicine cabinet turned on 24 hours a day.)
|
Product Model |
Product Parameters |
configuration |
optional configuration |
|
GS-G819 |
External Dimensions: 819354725mm Internal Dimensions: 753322519mm Molecular Filter Dimensions: 18539550mm Number of Shelves: 2 Shelf Load - bearing Capacity: >70kg/㎡ Air Treatment Capacity: 75m³/h Storage Capacity: 48 bottles (500ml) Volume: 45 dBA Voltage: 220V/50HZ Power: 42W Current: 0.17A |
Molecular filters: 2 sets Number of fans: 1 Shelves: 2 pieces Display screen: 7 - inch LCD touch - screen Control system: 1 set Filter saturation alarm system: 1 set Temperature and humidity alarm system: 1 set Power cord: 1 piece |
Optional filter models: SFGL OG: Organic filter SFGL AG: Inorganic filter HEPA H14: HEPA filter PREFIL: Pre - filter Lighting strip: 1 set Notes: All configurations are included for the first purchase. This type of medicine cabinet does not work well for storing solid powders. |
Sturdy and Durable
The main body of the fume hood is made of galvanized steel sheets with a thickness of ≥1.2mm. After being treated with epoxy resin electrostatic spraying and a chemical - resistant lead - free coating, it has a stable structure and strong corrosion resistance, enabling it to operate stably in experimental environments with high humidity and strong chemical corrosion. The front and side panels made of acrylic sheets with a thickness of ≥6mm not only have excellent weather resistance but also possess outstanding chemical - resistant properties and good light transmittance, facilitating experimental operations and observations.
Intelligent and Efficient
It is equipped with a 7 - inch 1024*600 high - definition LCD touch - screen, which is convenient to operate. It integrates intelligent systems such as temperature and humidity monitoring, fan status monitoring and adjustment, and filter saturation early warning, allowing real - time monitoring of the equipment's operating status and precise control to ensure experimental safety. The 24 - volt PSC fan imported from the United States operates stably, quietly, and without static electricity. Combined with a high - efficiency filtration system that follows ASTM standards, it has a remarkable adsorption and filtration effect on various harmful gases and particles, effectively purifying the experimental environment.
Basic Scientific Research Field
In basic scientific research laboratories such as those for chemistry, biology, and pharmaceuticals, the fume hood plays a crucial role. It can effectively filter out various harmful gases generated during experiments, such as volatile acid - base gases in chemical experiments, microbial aerosols in biological experiments, and volatile organic reagents in pharmaceutical experiments, providing a safe experimental environment for researchers and ensuring the smooth progress of experiments.
Emerging Industries Field
In laboratories for emerging industries such as electronic chip manufacturing and new energy material research and development, the fume hood is also indispensable. In the photolithography and etching processes of electronic chip manufacturing, it can filter out the generated harmful gases, maintaining a clean experimental environment and ensuring the high precision of chip manufacturing. In new energy material research and development, it can handle flammable, explosive, toxic, and harmful gases generated during the material synthesis process, promoting the innovative development of new energy technologies..
