Our ductless fume hood series meets the NFX 15 211:2009 standard (certified by ANSI Z 9.5 - 201), the ASHRAE 110:1995 standard, and the Chinese national standard JG/T385:2012. It is also ISO9001 - certified. Specifically designed to safeguard the safety of laboratory personnel during experiments, this product prevents operators from inhaling toxic, harmful, disease - causing, or chemicals with unknown toxicity. It efficiently purifies the air inside the fume hood and the laboratory, providing reliable safety protection for users.
Metal Components: The main material is galvanized steel plate with a thickness of at least 1.2 mm. It undergoes electrostatic epoxy resin spraying and is coated with a durable, chemical - resistant, lead - free finish. This not only maintains a high - gloss surface but also minimizes the impact of corrosion and moisture.
Front and Side Panels: Made of acrylic plate with a thickness of at least 6 mm, these panels offer excellent weather resistance and chemical resistance. They are resistant to aging, colorless, transparent, and allow light to pass through uniformly. This design provides a comfortable visual experience and an aesthetically pleasing appearance.
*3. Seven - inch LCD Touch Screen: With a high - definition resolution of 1024×600, it offers a perfect visual experience for easy operation.
*4. Real - time Temperature and Humidity Monitoring System: This system displays temperature and humidity levels and allows users to set alarm parameters, ensuring the safe use of the product.
*5. Fan Monitoring: An alarm will be triggered if the fan system malfunctions. The fan speed can be adjusted online to meet the air volume requirements of different chemical operations.
*6. Filter Saturation Alarm System: A saturation alarm value is set for the filter. Once the limit is exceeded, an alarm will sound, corresponding to the VOC concentration level. When both the alarm and the concentration level are high, the filter needs to be replaced.
Imported PSC Fan from the United States: Operating at 24 volts, this fan offers stable performance, ultra - quiet operation, and is free from sparks and static electricity.
High - efficiency Filtration System: The filters are arranged according to particle size, following the ASTM standard. They are highly effective in adsorbing acidic and organic gases. A high - efficiency HEPA filter is used for particles, achieving a filtration efficiency of 99.995% for particles larger than 0.3 μm.
LED Lighting: With a power equivalent to a 25 - watt fluorescent lamp, the LED lighting generates no heat, ensuring safety without affecting the experimental environment temperature. It is energy - efficient, environmentally friendly, and has a long lifespan.
Epoxy Resin Tabletop: The epoxy resin tabletop features superior chemical stability, excellent corrosion resistance, good impact resistance without damage, and outstanding high - temperature resistance. It has an integral through - core structure, a long service life, and is resistant to delamination, expansion, and cracking.
Easy Installation and Environmental - friendliness: No pipeline installation is required, making the installation process quick and simple. The waste gas is not discharged outdoors, making it an environmentally friendly solution. Customizable Filter Module System: The top of the fume hood can be optionally equipped with a filter module system according to experimental requirements, meeting the needs of various experiments.
Advanced Modular Filtration Technology: This technology can completely adsorb and filter harmful gases, particulate dust, and other substances generated during experiments.
Energy - saving: It does not consume air - conditioning energy, resulting in significant energy savings.
Flexible Placement: The fume hood can be placed on a desktop or equipped with a mobile wheel base, making it suitable for any complex experimental location.
Air Inlet
Air is directly drawn from the laboratory into the fume hood, creating a negative pressure. A stable face velocity forms a natural barrier that isolates users from the chemicals they are handling.
Comprehensive Filtration System
The fan system sucks in toxic and harmful gases, which are then filtered before the clean air is returned to the room. The excellent concentration control of the cabinet ensures that no chemical gases leak back into the room, preventing pollution.
Purifying Laboratory Air
Different filters can be configured according to different operations to effectively filter toxic and harmful gases, purify the laboratory air, remove chemical odors, and improve the laboratory cleanliness level.
Purifying Surrounding Air
The continuous filtration efficiency of the fume hood helps to purify the indoor air.
|
Product Model |
Product Parameters |
configuration |
optional configuration |
|
GS-DM1275 |
External dimensions: 1275×620×2070 mm Internal dimensions: 1172×552×866 mm Molecular filter dimensions: 370×395×50 mm Pre - filter dimensions: 370×395×21 mm Air handling capacity: 460 m³/h Average surface wind speed: 0.4 - 0.6 m/s Voltage: 220 - 240 V Frequency: 50 - 60 Hz Maximum current: 2 A Sound level: 52 dBA Power: 126 W Operation hole types: Triangle (Ellipse, Trapezoid) |
Molecular filters: 6 sets Primary filters: 3 pieces Fans: 3 units Lighting: 1 set of LED lights Display screen: 7 - inch LCD touch screen Control system: 1 set Filter saturation alarm system: 1 set Temperature and humidity alarm system: 1 set Power cord: 1 piece |
Fixed base Mobile base Epoxy resin countertop Stainless steel countertop Tempered glass countertop Optional filter models: SFGL OG: Organic filter SFGL AG: Inorganic filter HEPA H14: HEPA filter PREFIL: Pre - filter |
The ductless fume hood with air purification features outstanding design and performance. It uses high - quality materials. The galvanized steel plate combined with a special coating makes it sturdy and corrosion - resistant, while the acrylic plate is transparent, weather - resistant, and chemical - resistant. In terms of functionality, it integrates intelligent monitoring and high - efficiency filtration. The touch - screen operation is intuitive, allowing for precise adjustment of parameters such as temperature, humidity, and fan speed. It can also purify the air according to the characteristics of pollutants, being highly efficient, energy - saving, and environmentally friendly.
In terms of applications, the fume hood has a wide range of uses. Besides the common chemical, biological, and pharmaceutical laboratories, it also plays an important role in laboratories for electronic chip manufacturing, food testing, forensic evidence analysis, etc. It can effectively filter harmful gases and ensure the safety of the experimental environment. Looking forward, the fume hood will develop in the directions of intelligent integration, development of new filtration materials, and optimization of energy - saving designs to meet the needs of more fields.
